Tube fitting FE-S

T

TUBE

O.D.

PT-NPT

MALE

PIPE SIZE

CATALOG

NUMBER

A

C

D

E

F

G

H

6

1/8

FE-6-1

27.0

19.1

15.3

5

14

14

19.6

6

1/4

FE-6-2

29.8

22.4

15.3

5

17

14

22.4

6

3/8

FE-6-3

34.6

22.4

15.3

5

22

14

27.2

6

1/2

FE-6-4

37.7

26.4

15.3

5

27

14

30.3

8

1/8

FE-8-1

29.3

20.0

16.2

6

14

17

21.8

8

1/4

FE-8-2

30.6

22.4

16.2

6

17

17

23.1

8

3/8

FE-8-3

34.0

27.7

16.2

6

22

17

26.5

8

1/2

FE-8-4

36.8

31.7

16.2

6

27

17

29.3

10

1/8

FE-10-1

31.5

19.0

17.2

8

17

19

23.9

10

1/4

FE-10-2

33.5

22.4

17.2

8

17

19

25.9

10

3/8

FE-10-3

37.5

27.7

17.2

8

17

19

29.9

10

1/2

FE-10-4

40.3

31.7

17.2

8

22

19

32.7

12

1/8

FE-12-1

36.0

22.4

22.8

10

22

22

25.9

12

1/4

FE-12-2

36.0

22.4

22.8

10

22

22

25.9

12

3/8

FE-12-3

36.0

22.4

22.8

10

22

22

29.9

12

1/2

FE-12-4

38.8

28.4

22.8

10

27

22

28.7

12

3/4

FE-12-6

41.8

32.4

22.8

10

32

22

31.7

14

3/8

FE-14-3

39.8

25.4

24.4

10

27

27

29.7

14

1/2

FE-14-4

39.8

28.4

24.4

10

27

27

29.7

14

3/4

FE-14-6

42.8

32.4

24.4

10

32

27

32.7

15

3/8

FE-15-3

39.8

25.4

24.4

11

27

27

29.7

15

1/2

FE-15-4

39.8

28.4

24.4

11

27

27

29.7

15

3/4

FE-15-6

42.8

32.4

24.4

11

32

27

32.7

16

3/8

FE-16-3

39.8

25.4

24.4

12

27

27

29.7

16

1/2

FE-16-4

39.5

28.4

24.4

12

27

27

29.7

16

3/4

FE-16-6

42.8

32.4

24.4

12

32

27

32.7

18

3/8

FE-18-3

40.5

25.4

24.4

14

27

30

30.4

18

1/2

FE-18-4

40.5

28.4

24.4

14

27

30

30.4

18

3/4

FE-18-6

43.5

32.4

24.4

14

32

30

33.4

20

1/2

FE-20-4

43.5

31.4

26.0

16

32

32

33.4

20

3/4

FE-20-6

46.5

35.4

26.0

16

32

32

36.4

22

1/2

FE-22-4

43.5

31.4

26.0

18

32

32

33.4

22

3/4

FE-22-6

46.5

35.4

26.0

18

32

32

36.4

25

1/2

FE-254

47.5

33.4

31.5

21

34

38

35.2

25

3/4

FE-25-6

50.5

37.4

31.5

21

34

38

38.2

1/4

1/8

FE-02-1

27.0

19.1

15.3

5

14

14

19.6

1/4

1/4

FE-02-2

29.7

22.4

15.3

5

17

14

22.4

1/4

3/8

FE-02-3

32.6

22.4

15.3

5

22

14

27.2

1/4

1/2

FE-02-4

37.7

28.4

15.3

5

27

14

30.3

3/8

1/8

FE-03-1

30.5

19.8

16.8

7

17

17

23.1

3/8

1/4

FE-03-2

31.2

22.4

16.8

7

17

17

24.0

3/8

3/8

FE-03-3

33.3

22.4

16.8

7

22

17

26.0

3/8

1/2

FE-03-4

36.1

28.4

16.8

7

27

17

28.7

1/2

1/8

FE - 04-1

36.0

22.4

22.8

10

22

22

25.9

1/2

1/4

FE-04-2

36.1

22.4

22.8

10

22

22

26.0

1/2

3/8

FE-04-3

36.1

22.4

22.8

10

22

22

26.0

1/2

1/2

NFE-04-4

39.0

28.4

22.8

10

27

22

28.7

1/2

3/4

NFE-04-6

41.8

32.4

22.8

10

32

22

31.7

5/8

3/4

NFE-05-6

42.8

32.4

24.4

12

32

27

32.7

3/4

1/2

NFE-06-4

39.9

28.4

24.4

15

27

30

29.7

3/4

3/4

NFE-06-6

44.7

32.4

24.4

15

32

30

34.5

1

3/4

NFE-08-6

49.0

32.4

31.3

21

34

38

36.8
