1401 Capsule low pressure gauge

Designation

Standard industrial series

Model

1401

Applications

Gaseous and dry media

Nominal size: (mm)

Ø(50, 63, 94, 121)

Scale ranges

 -600-0. 0-25 to 600mbar

Accuracy class

2.5Ø(50, 63, 94, 121)

Pressure connection

1/8"Ø(50) 1/4"Ø(50-121)

Wetted parts

Copper alloy

Case material

Black steel caseØ121 with bezel ring

Window

Acrylic

IP class

IP 43

Options/notes

Lower or back entry, Ø 50 only back, Ø 94, Ø121 only lower,Ø63 available with panel mounting
